The roller processing equipment designed this time mainly includes steel pipe automatic cutting machine tool, steel pipe double-end automatic drilling machine tool, carbon dioxide gas protection automatic welding machine tool, etc.
(1) Idler pipe cutting machine
Model: CO160
Applicable pipe diameter (outer diameter) range: Ф89, Ф108, Ф133, Ф159, Ф194, Ф219mm, applicable pipe wall thickness range: 3~12mm
Applicable pipe raw material maximum length: 9000mm, host center height: 1000mm
Spindle speed: 50~250r/min
Feed speed: 0~60mm/min
Cutting length range: 180mm~2600mm, cutting pipe length when blue 800, cutting length error: three, 0.2mm length is greater than 800mm, and the error reaches IT9 level accuracy
Parallelism tolerance at both ends of the cut-off: 9 grades
Surface roughness of cutting and chamfering: 6.3~12.5
For example: roller double-head automatic welding machine
Input power: three-phase 380v50Hz applicable welding wire: Ф1.2~1.6mm shielding gas flow: 10~25L/min weldable workpiece length: 300~2600mm weldable workpiece diameter: Ф89~Ф219 spindle speed: 0~10rpm clamping cylinder stroke: 200mm welding torch left and right adjustable angle: ±20° Machine size: 5100x880x1700mm
